High Strength PEEK
High-Strength PEEK is formed through the production of PEEK filaments from PEEK particles. High-Strength PEEK has a tensile strength of 270 MPa, while retaining the thermal and chemical robustness of traditional PEEK resins. High-Strength PEEK is an excellent replacement in applications where traditional PEEK filament products are currently used.
Key Advantages:- High-Strength PEEK has excellent high temperature resistance, with a continuous use temperature of 260 °C.
- High-Strength PEEK possesses outstanding mechanical properties, with a tensile strength of 270 MPa.
- High-Strength PEEK combines toughness and rigidity, making it an ideal choice in many applications.
- High-Strength PEEK’s strength and fatigue resistance values outperform metal and alloy materials.
Material Properties:
| Specification |
Measurement |
| Density |
1.45 g/cm3 |
| Shrinkage |
0.10 % |
| Degree of Crystallization |
- |
| Water Absorption |
0.10 % |
| Tensile Strength |
270 Mpa |
| Tensile Modulus |
25 Gpa |
| Bending Strength |
340 Mpa |
| Flexural Modulus |
21.5 Gpa |
| Compressive Strength |
323 Mpa |
| Elongation at Break |
1.7 % |
| Continuous Use Temperature |
260 °C |
| Heat Deflection Temperature |
170 °C |
| Volume Electric Resistivity |
- |
| Dielectric Loss |
- |
| Dielectric Constant |
- |
| Rockwell Hardness |
- |
