PEEK for Gears
$0
Unit of Measure
In stock
Product Details
PEEK for Gears is a specially-designed material, tailored to produce gears. It is intended for production ofheavy-duty as well as precision machined gears. For many applications, gears made from PEEK for Gears can replace gears made from steel or other metals.
Key Advantages:
- PEEK for Gears has high tensile strength.
- PEEK for Gears has excellent wear resistance with a wear rate of less than 0.05%.
- When compared to gears made from other plastics, the toughness, impact resistance and hardness properties of PEEK for Gears have all been improved.
- Gears made from PEEK for Gears can run at high speed, with excellent accuracy and low noise characteristics.
Material Properties:
| Specification |
Measurement |
| Density |
1.30 g/cm3 |
| Shrinkage |
0.08 % |
| Degree of Crystallization |
30 % |
| Water Absorption |
0.02 % |
| Tensile Strength |
180 MPa |
| Tensile Modulus |
19 GPa |
| Bending Strength |
280 MPa |
| Flexural Modulus |
17 GPa |
| Compressive Strength |
300 MPa |
| Elongation at Break |
1.9 % |
| Continuous Use Temperature |
210 °C |
| Heat Deflection Temperature |
170 °C |
| Volume Electric Resistivity |
105 Ohm |
| Dielectric Loss |
- |
| Dielectric Constant |
- |
| Rockwell Hardness |
107 |
